| Product code: | AN2/TIGER/SHIMA |
| Power Supply: | 3V DC |
| Electrical absorption: | 8mA |
| Working temperature: | -10+55° C |
| Channels: | 2 |
| Encoding: | Fixed or Rolling Code |
| Modulation: | AM/ASK |
| Carrier frequency: | 433.92Mhz |
| Combinations: | 65.536 (fix code) – 4.294.967.296 (Rolling Code) |
| Type of fixed codes clonable: | MANCHESTER, PCM, Max64bit |
| Bit number of identification code: | 16 (fix code) – 32 (Rolling Code) |
| Number of bits transmitted: | 28 (fix code) – 144 (Rolling Code) |
| Copy function: | Yes (only fix code) |
| Maximum distance open field: | 150m |
| Battery: | MOD “CR2032” 3V |
| Packed product weight (kg): | 0.04 |
